Cells Per Unit

6

Voltage Per Unit

12 V

Capacity

96.7W @ 5min-rate to 1.6V per cell @25°C (77°F)

Weight

Approx. 2.83 kg (6.24 lbs)

Maximum Discharge current

130 A (5sec)

Internal Resistance

Approx. 11.8 mΩ

Operating Temperature Range

Discharge：-15℃~50℃ (5°F~122°F) Charge：-15℃~40℃ (5°F~104°F) Storage：-15℃~40℃ (5°F~104°F)

Nominal Operating Temperature Range

25°C ±3°C (77°F ± 5°F)

Float charging voltage

13.5 to 13.8 VDC/unit Average at 25°C (77°F)

Recommended Maximum Charging current limit

4.80 A

Equalization Charging Voltage

14.4 to 15.0 VDC/unit Average at 25°C (77°F)

Self Discharge

Less than 10% after 90 days, can be stored up to 6 months at 25℃ (77℉)

Terminal

F2-Faston Tab 250

Container Material

ABS (UL 94-HB) & Flame Retardant (94-V0) available upon request
